Cure Through Wedge Wands® Refills

The Cure Through Wedge Wands® interproximal wedges are made from a translucent material which allows curing penetration deep into the interproximal space when using light cured composite material. The cure-through design allows for curing light penetration directly to the critical gingival floor.

The Wand applicator provides the simplest placement technique ever. No instrument, no hassles. The most anatomical shape available, patient-friendly features reduce trauma to the papilla.

WCYL Dimensions

• 2.03 mm height (tallest point)
• 2.03 mm width (widest point)
• 77.7 mm length (with handle)
• 14.99 mm length
• 3.6 mm handle diameter

WCBL Dimensions

• 2.54 mm height (tallest point)
• 2.54 mm width (widest point)
• 80 mm length (with handle)
• 16.76 mm length
• 3.6 mm handle diameter

WCOR Dimensions

• 2.54 mm height (tallest point)
• 2.54 mm width (widest point)
• 81.2 mm length (with handle)
• 17.27 mm length
• 3.6 mm handle diameter

WCGR Dimensions

• 3.43 mm height (tallest point)
• 3.43 mm width (widest point)
• 82.1 mm length (with handle)
• 18.8 mm length
• 3.6 mm handle diameter

Materials

• Nylon
